LED Neon Strip Lights
Neon LED light strips innovate through material science and functional integration, overcoming traditional LED limitations in protection, safety, and adaptability. Their multi-scene compatibility and cost efficiency make them a pragmatic yet aesthetic solution for modern lighting design.
LED Strip Lights
LED strip lights are versatile lighting solutions that offer energy efficiency, long lifespan, and customizable designs. They come in two main types: COB (Chip-on-Board) LED strip lights, which provide a continuous, uniform light output ideal for seamless applications, and SMD (Surface-Mounted Device) LED strip lights, known for their flexibility and variety in brightness and color options. Both types are easy to install and can be used for accent lighting, task lighting, or decorative purposes, enhancing any space while reducing electricity costs.
LED Strips Connectors
YIFORD offers a wide range of solderless connectors designed for LED strip lights, simplifying installation without the need for soldering. Our product lineup includes board-to-board, board-to-wire, wire-to-wire, L-shaped, and T-shaped connectors, with hundreds of styles available. Compatible with nearly all widths and models of LED strip lights on the market, our connectors ensure reliable connections for both DIY enthusiasts and professionals.
Silicone LED Channel System
Silicone light strips are very soft and can be bent, twisted, and stretched freely, suitable for complex design and installation environments. It has strong weather resistance, is not easy to crack, and has a long service life. Silicone light strips are usually designed with low voltage, which improves the safety of use. In addition, silicone material itself has characteristics such as fire resistance, gas corrosion resistance, and UV protection, which can work stably in harsh environments.
Light Accessories
LED Controller
The LED controller is a chip that processes and controls the switches at various positions in the LED light circuit. The controller controls the driving circuit according to the pre-set program to make the LED array emit light in a regular manner.
Power Supply
The standard packaging of LED flexible light strips is 5 meters in a roll, but 5 meters are often not used directly in daily applications, and some light strips are often cut or re-connected, how to cut led light strips and some problems related to cutting will be involved here.
The LED light strip is like a luminous ribbon, while providing incredible flexibility. Its characteristics allow the light strips to have many functions, and it is widely used in various places and areas of life. They are the perfect lighting for room. with excellent lighting solution We’ve prepared a guide to help you to know everything you need to know about cutting LED light strips. Here we use the new type flexible lighting COB （chip on board) light strips as a case to explain：
Yes. you can, no matter SMD led strips or COB led strip lights. All our LED strips can be cut.
Avaliable from 10mm to 100mm different length, It depends on the type of LED strip lights you have.
The cutting interval of COB light strip is as follows:
The above is the single-color cutting length. New and customized types are not listed. YIFORD will introduce COB light strips with more specifications and cutting lengths to the market in the future. Let’s take a look at the cutting line lengths of multi-color light strips
The 12V and 24V tunable white CCT color temperature led strip lights cutting lengths of the positive are the same, 12V RGB led strips and 24V RGB led strips led quantity per meter are different, and the cutting lengths are also different.
The cutting length of 24V and 12V led strip lights is not multiplied, it is determined by the internal circuit diagram design of the PCB (Print Circult Board )
The chipset on the COB light strip are small and dense, and the number of led chip is not easy to count, so it is good to cut according to the cut position marked.
Exactly – very easy. Cut COB led strip lights according to the cutting line, using a pair of scissors or a sharp knife. Be careful not to cut outside of the cutting points.
The led strips is with cut point, The cut point is marked by a thin line on the copper circult board. beside is with copper dots marked + positive and – negative. sometimes we call it cut line.
Although the length of each cut varies, the cut points are evenly distributed along the length of the strip.
Yes, you can, but not recommend. The cut ends of the LED strip is not electrically conductive. You can cut the LED strip anywhere you like. However, doing so will not cause the extra lights to light up.
After the cut is wrong, the group of light strips at the end will not light up, just cut off the group that does not light up. double check the cut line before cut led strip lights. if you cut an led strip with wrong cut line, please stop re connect led strip lights from the wrong parts.
It is better to cut a small quantity by yourself. If you want to cut a large quantity with the same length, you can cut it on the machine. YIFORD can cut and mark it for you free of charge.
We know that most people don’t know how to solder or have a soldering iron on hand, so we now have a variety of solderless connectors for our LED strips that can be used to join two lengths of strip lights end to end.
Unfortunately, we do not allow returns on custom strips because it is almost impossible for us to resell the product (unless someone else is looking for the exact same length of led strip lights).
Practical demonstration reference here：
you will get know all the details how to install led strips for your projects. step by step.
You may interesting how to reconnect led strip lights
you will get know all the details how to install led strips for your projects. step by step.
You can leave a message on our website. Or you can send email to info@yiford.com. Our sales engineers will be more than happy to assist you.
Suspended mount, generally can also be used for recessed mount, surface mount, Yiford is with variety of installation accessories can be choosed.
Whatever your domestic or commercial lighting project, our easy-to-install suspendable LED profiles offer a stylish look and finish to complement the aesthetic in your task zones,
This led strip light channel can accommodate LED strips/tape/ribbon that are 8-10.5 millimeters wide.Metal mounting clips provides easy and secure installation.Frosted Light diffuser slightly diffuses the light to create softer,smoother,desirable lighting effect.
Aluminum LED channel is anodized extruded, great in heat dissipation, while the LED diffuser cover protects the LED strip from dust and physical contact, extend the life span of flexible led light strips.
Round Tube
Topview Tube
Sideview Tube
With Fringe
Black Tube
Half Cover Sleeve
COB LED Strip Lights
