White 8mm 384Leds 24V

Model NO.
YF-JWD24BB20X-384
1、Wide beam angle, 180 degree

2、PCB width 8mm, 24VDC, 384leds/metre

3、High CRI>90, SDCM<5, restore true color

4、No dark area, perfect light performance

5、High lumen output, more than 1000lm/meter

6、Widely used in decoration and accents lighting such as bar, hotel, shops, gardens,etc
Product Specification
Product Name384leds 24V cob led strips
ModelYF-JWD24BB20X-384
LED QTY/Metre384LEDs
PCB Thickness2 oz
PCB ColorWhite
Adhesive TapeDouble side adhesive
Length per reel16.4′ (5M) or 32.8′(10M)
Standard Connector20AWG red/black cable on the end
Length of Cuttable41.6 mm
PCB width8 mm
LED Strip Dimension8mm (Width) *2.3mm(Height) *Length
Length5000mm (16.4ft) per roll
Connection Cable150mm length
Electrical Parameters
ModelYF-JWD24BB20X-384
Color2700K/3000K/ 4000K/ 6000K
Light Efficiency100 lm/watt
Input VoltageDC24V
Ra>90
LED Beam Angle180°
Lumen Output/Metre800 / 850 / 900 / 950
Operating Temp.: -25°C~ +45°C
Storage Temp.:-25°C~ +70°C
Working Humidity40%-70%RH
Working Lifetime25,000+ hours
Power10W/Metre
Warranty3 years



To understand the advantages of COB light strips, please click:
Detailed introduction to the advantages of COB light strips

To find the most suitable COB light strip and purchase the installation guide, please click:
COB LED Strip Lights Buying Guide

To know the most detailed features of COB and what the 18 features do, please click:
COB LED Light Strips Most Complete Introduction

If you want to know how to better apply COB light strips, here are the cases in 13 fields, please click:
What are application ideas for LED Strip Lighting?



cob led strip lights 384leds 24V,cob led strip,cob led light strip,led strip cob, dotless led strip,, whtie 8mm 384leds,
