Violet COB 12V/24V 320/384/480/528leds

Model NO.:: YF-JVDXX

1、Wide beam angle, 180 degree

2、PCB width 5mm/8mm/10mm,12V or 24VDC,
320/384/480/528pcs LED per metre

3、Avaliable White/Red/Green/Blue/Yellow/Pink/Violet/IceBlue

4、No dark area, perfect light performance

5、High lumen output, 100lm/W,

6、Widely used in decoration and accents lighting such as bar, hotel, shops, gardens,etc

Quantity:

Product Description

Product Specification
Product Name	Violet 24V cob led strips	Violet 12V cob led strips
Model	YF-JVD24XX	YF-JVD12XX
LED QTY/Metre	320/384/384/528pcs led per metre
PCB Thickness	2 oz
PCB Color	White
Tape	Blue conduct heat adhesive tape
Length per reel	16.4′ (5M)
Standard Connector	20AWG red/black cable on the end
Length of Cuttable	50mm/41.6mm/41.6mm/45.5mm
PCB width	8mm/8mm/5mm/10mm
LED Strip Dimension	8/8/5/10mm (Width) 2.3mm(Height) Length
Length	5000mm (16.4ft) per roll
Connection Cable	150mm length

Electrical Parameters
Model	YF-JVD24XX	YF-JVD12XX
Input Voltage	DC24V	DC12V
Color	Violet
Wave Length	375-385nm
LED Beam Angle	180°
Operating Temp.:	-25°C~ +45°C
Storage Temp.:	-25°C~ +70°C
Working Humidity	40%-70%RH
Working Lifetime	25,000+ hours
Power	8W/10W/10W/14W per Metre
Warranty	3 years
